We were looking for a new fabric because of issues with the pilling of the Pertex Quantum Air. This had not been a problem during my field tests, but many customers complained that the fabric was prone to pilling in various situations. We wanted to solve this issue so that our customers can wear UL Shirts comfortably on their hikes without worrying about pilling.

So I collected a variety of lightweight, highly breathable fabrics from various companies. It was, however, difficult to define the reason why pilling occurred. The problem was not always reproduced, and in fact, my own UL Shirt never had any pilling issues. Pilling was obviously triggered by the repeated friction with something hard and coarse over a long period of time but it was very difficult to confirm from actual field testing. Hence, I realized that a reproducible testing method was necessary to validate and compare fabric issues, using inspection machines and tabletop testing. I also needed to know and understand why and how the pilling occurred in the first place because Pertex Quantum Air, the original UL Shirt fabric, performed pretty well in the normal abrasion testing. Then, what other trial method might be appropriate? We discussed this with the professional inspection company.

Consequently, after repeated tests, we concluded that the structure of the ripstop was the cause of the pilling.

Because the ripstop yarn is stronger and thicker than other yarns, it is higher than other yarns, thus creating unevenness in the fabric. When ripstop yarns are rubbed against hard objects, the yarns are partially pulled out and pilling occurs. We recognized that this is a problem that can occur not only with Pertex Quantum Air but with all ripstop fabrics.

Therefore, we decided to collect plain weave fabrics that are flatter and less prone to pilling, and also made a prototype of a proprietary plain-woven fabric. However, the plain-woven and thin fabrics were not strong enough and did not have the texture that I was looking for.

Then I thought of Teijin’s Shadow Rip. To prevent the surface from becoming uneven, the ripstop yarns of the fabric are made of a high-strength fiber that has the same thickness as the other yarns. This structure prevents the ripstop part from snagging and causing pilling of the fabric. Moreover, the fabric is strong and durable.

This is the perfect one I was looking for, I thought at first. Only, the fabric was heavier than the Pertex Quantum Air we had been using, and it was slightly thicker and made of polyester instead of nylon. Since we are an Ultra Light gear manufacturer, I was not happy about the heavier weight of the fabric. We decided to make a prototype and test it to see how it would perform.

Various tests have already shown that the breathability is equivalent to Pertex Quantum Air, and also in field tests in the mountains, the prototype turned out to be equally comfortable to our existing UL Shirts made of Quantum Air. It offers high ventilation performance when the buttons are wide open, and it can be windproof at the core of the body when the buttons are closed. The sleeves can be easily rolled up, or the neck collar can be raised and buttoned up when cold. It was as useful as ever and performed well as hiking activewear. Furthermore, I was also able to discover new features, such as superior wrinkle-proof performance even after it is tightly tucked into a backpack.

Consequently, we decided to update the fabric to Shadow Rip based on the following new advantages: it feels as comfortable as the previous fabric, it is less likely to create pilling due to repeated rubbing which had been a problem in the past, and it does not wrinkle easily even when squeezed into a backpack.

Yet another problem, however, was discovered.

Compared with nylon, the polyester fabric turned out to be more prone to color transfers to something. Shadow Rip is not our proprietary fabric but is developed by Teijin, and has been used by other major outdoor manufacturers for some time.

According to Teijin, color transfer has never been an issue so far. So, it was only in our individual tests conducted at a testing agency that the color transfer occurred. We confirmed staining on white wool and silk fabrics when they were layered and adhered to dark-colored Shadow Rip fabrics. Each of us has a unique composition of perspiration, and the color transfer does not occur in everyone, but now that we know this might occur, we want to be open and share this information with all of you.

To be honest, I was reluctant to write something negative about an updated product in this Product Story. But after many trials and tests, we discovered the solution as described in the “Product Story 2” in the next section.

I feel that it is better than our previous product and ready to go out to the world. I look forward to hearing everyone’s thoughts on this newly updated UL Shirt. (March 2022)

We recently changed the fabric of the UL Shirt from Pertex Quantum Air to Teijin’s Shadow Rip. The major difference is the material: The former is 100% nylon, whereas the latter uses 100% polyester. Many of our products use nylon, but this was the first time for us to use polyester. Both nylon and polyester are synthetic fabrics, but each has its own characteristics. The new Shadow Rip clearly taught us the difference between the two.

What is color fastness? It is a term used in the dyeing of textiles, meaning a dyed fabric’s level of resistance to color fading or color running. Major color fastness indexes include a change in color and staining to the adjacent fabric.

For quality assurance, we conducted an in-house test of the mass-produced Shadow Rip’s color fastness, and we were a bit concerned by some of the results. Dark colors, such as Black, Duck Green, or Terracotta fabrics performed poorly in the color fastness to perspiration test, which shows how the dyed fabrics are resistant to fading and running when they are wet from perspiration.

For a more detailed inspection of the color fastness, we selected four types of sample fabrics, cotton, wool, polyester, and nylon, to see how the color transfer occurs when each fabric is in contact with the Shadow Rip. As a result, we confirmed that the Shadow Rip’s color significantly transfers to wool, and a bit to nylon, but almost none to cotton and polyester.

The result of this color fastness test suggested that when a dark-colored Shadow Rip fabric is wet from perspiration, and is rubbed against white or light-colored wool fabrics for about eight hours, Shadow Rip’s color is transferred to the wool.

In your daily life, you rarely keep going for eight hours with a wet shirt. But we are talking about mountain gear, not casual clothes. You may walk on endlessly with a sweaty back. We had to make sure if the color transfer occurred in the actual field: mountains and trails.

In our in-house tests, Yamatomichi staff hiked for many hours and got soaked in sweat. The test samples were all our Shadow Rip products that were to be released and Yamatomichi Merino T-shirts including the colors that had no problem in the testing machine environment to analyze every combination of Merino T-shirts and Shadow Rip colors.

To verify all possible color combinations, the testers walked and ran on and off the trails for several hours to half a day, so that they sweat heavily while wearing the 100% Merino shirts and Shadow Rip UL Shirts in different colors, carrying backpacks on their backs. For efficiency, we also made a prototype called the “Two-Face”, a single garment with a different color on the left and right sides. A total of 10 testers tested 7 colors of Shadow Rip shirts, and 9 colors of merino shirts for 80 hours of testing duration in total.

As a result, we confirmed that the color transfer occurred in the combination of dark-colored Shadow Rip fabrics and light-colored merino fabrics, which also proved the experiments performed in the testing machines. The light-colored Shadow Rip, which had excellent results in the color fastness test did not cause color transfer, and the dark-colored merino fabrics were not influenced by color transfer, or the color transfer was not recognizable at all.

Our understanding was that the perspiration triggered the color transfer, so the likeliness of color transfer or color bleeding depends on each person because we all eat and drink differently, and each of us has different components of sweat. In the field test, however, the color transfer occurred in all testers. We thought, what if the sweat was not the major reason? We carefully checked the results of the color fastness test and some scores showed that the color fastness of water, not limited to perspiration, performed poorly. The results suggested that if the Shadow Rip got wet, not only by sweat, and in contact with white or light-colored fabric, the color transfer occurred.

Thus, we initiated a thorough investigation. The indexes include the color fastness to washing, perspiration, water, friction/rubbing, etc., and clothing companies control the quality of their products by setting the acceptability criterion individually. The common grading of color fastness ranges from 5 (outstanding) to 1 (very poor) with an intermediate grade between two grades. For example, the Grade 4-5 is set between the Grade 4 and Grade 5, so there are nine grades in total. Some casual clothes pass the quality control test if they are graded 3-4, and if graded 4, they are satisfactory for most manufacturers.
We tested 100% polyester clothes by other outdoor gear makers marked Grade 4 in fastness to both perspiration and water. It seemed that Grade 4 was the acceptability criteria for many outdoor brands, but we experienced stains caused by color transfer on white sample fabrics even though they were graded 4.

We adopted the Shadow Rip for shirts, which meant that hikers were likely to wear them over the base layer T-shirts. The Shadow Rip shirts may be in contact with all kinds of base layer T-shirts, soaked in sweat for many hours, so we need to be ready for the possible color transfer, and how to deal with them if they occur.

What are the characteristics of polyester fabrics? We manufactured many nylon clothes but were not fully knowledgeable about polyester, the material of the Shadow Rip. Compared to natural fibers such as cotton and wool, synthetic fibers including nylon and polyester are considered less prone to color fading or transfer. According to our field test, however, the color transfer did occur in many situations, sometimes quite easily.

Upon further research, we learned that polyester is resistant to color fading and color transfer, except for prolonged submersion in water. To summarize, the cause of color transfer of polyester fabrics, which are said to be resistant to color transfer, is as follows: In the finishing process of fabrics, the excess dye remaining in the fibers is usually removed by washing, and then the color is firmly stabilized. But if the process of dye removal is inadequate, the unfixed dye may remain on the fibers and the color may bleed out when moisture gets on the fibers or when they are washed.

Is the color transfer of the Shadow Rip also caused by the remaining dye in the manufacturing process? We compared the unwashed Shadow Rip fabrics and the ones that were washed several times to see the difference of color fastness of both fabrics. As a result, the latter performed much better in the Color Fastness Test, meaning that the color transfer was less likely. Namely, the washing process removed the remaining dye in the fibers.

We shared this information with the fabric manufacturer, and they shared their detailed finishing process of the fabric. According to them, normally the dye is stabilized at a high temperature, but for this fabric, it was set a little lower to enhance the soft texture. It was possible that the low temperature of the dye stabilization process was the cause of the relatively poor color fastness performance. In exchange for the soft and comfortable texture, the color fastness test may have scored lower than usual. The person in charge also told us that polyester is generally more prone to color transfer than nylon.

Solution

This information was proven by the experiment performed by the testing agency. According to their explanation, polyester fibers are more weakly combined with the dye than nylon, depending on how they are dyed. They also taught us that if there is even a slight mismatch in dyeing conditions, the dye is less stabilized, thus causing the possible color fading and color transfer.

We confirmed that after the excess dye was washed out, the color fastness of dark-colored Shadow Rip fabrics improved and was graded as 4-5 or even 5, and there was almost no concern about color transfer. Therefore, we decided to sell the items after pre-washing them at the factory to remove the excess dye in the fibers.
This is how our new Shadow Rip items were launched. The tests and investigations gave us an opportunity to deepen our understanding of color fastness. The grading of color fastness is a theoretical criterion and it functions as a rough standard, and is not always perfect. It is necessary to make judgments by setting our acceptability criteria based on each product’s concept, usage situations, and other factors. Our research on color fastness will be summarized on our webpage shortly.

If color fastness is a priority, only limited colors will be available. For us, however, both function-oriented design that maximizes the usability, and freedom of color choice are equally important. While we continue to improve the resistance to color fading as much as possible, we will keep disclosing information and enhancing transparency so that customers can check if there is any possibility of color transfer in advance.
